Description
| BRAND | ZTE |
| MODEL | MF286C |
| SERIES | Wi-Fi Router |
| FEATURES |
 Supports 4G LTE CAT6 & High-Speed Ethernet
 300 Mbps Download
 50Mbps Upload
 2G – B4
 3G – B1/8
 4G – FDD B1/3/5/7/8/28, TDD B38/40/
|
| INTERFACE |
4 x RJ45 (GE x WAN/LAN + 3 LAN)
2 x RJ11 + 1 x USB
|
| WI-FI | 5GHz: Up to 867Mbps 2.4GHz: Up to 300Mbps |
| FREQUENCY BANDS | LTE: B1/B3/B7/B8/B20/B38/B40/B41 UMTS: B1/B3/B8 |
| DATA RATE | 4G: 3GPP R10, Cat. 4, Downlink/Uplink up to 150Mbps/50Mbps 3G: 3GPP R7 Downlink/Uplink up to 42Mbps/5.76Mbps |
| DATA RATE | IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz |
| LTE BAND | 1.4/3/5/10/15/20 MHz |
| ANTENNA | 4 Fixed External Antennas and 1 Internal Antenna |
| CPU | Qualcomm MDM9x07 / MDM9x25 |
| MODULATION | Downlink: QPSK/16-QAM/64-QAM Uplink: QPSK/16-QAM |
| LED | POWER: Power/Battery Status Indicator Network: 4G/3G/2G Network Status Indicator Wi-Fi: Wi-Fi Status Indicator |
| WebUI SYTEM | Connection Status Statistics Samba (optional) Device Management Power Management |
| WebUI ROUTER | USB RNDIS Device Up to 10 Wi-Fi users/devices DHCP Server IPv4/v6 VPN Passthrough Firewall WPS Security via WEP, WPA-PSK, WPA2-PSK Wi-Fi Settings |
| WebUI MOBILE SERVICE | Automatic APN matching according to USIM Auto Data Connection USSD Service PIN/PUK Management Network Mode Selection(2G/3G/LTE/Auto) |
| OPERATING SYSTEMS | Windows: XP/7/8/10 MAC OS: 10.7+ Linux: Ubuntu 13.04+ Browser: IE9+, Firefox, Google Chrome, Safari, Opera |
| POWER SUPPLY | USB, 5V1A |
| BATTERY | Type: Li-ion Polymer Battery Capacity: 2000mAh Endurance: 5-6 hours (normal network situation) |
| RF POWER LEVEL | LTE FDD: Power Class 3 (23 +/-2dBm) UMTS: Power Class 3 (24 +1.7/-3.7dBm) EDGE: Power Class E2 (GSM850/900: 27dBm; DCS/PCS: 26dBm) |
| OPERATION TEMPERATURE | 0°C to 35°C |
| STORAGE TEMPERATURE | -20°C to 60°C |
| CERTIFICATION | 3GPP Compliance: CE/FCC/GCF, upon customer’s requirement Material: RoHS |
| WEIGHT | 92g |
| CONDITION | Preowned |
| DIMENSIONS | 9.1 × 5.7 × 1.4 in (230 × 144 × 35 mm) |
| WARRANTY | 12 Months warranty |
| WHAT’S IN THE BOX | ZTE MF286C LTE + 4G Router Preowned  x 1 |
