Description
BRAND | TP-Link |
MODEL | EC220-G5 |
SERIES | Routers |
FEATURES | AC1200 Dual Band Wi-Fi: Delivers total Wi-Fi speeds up to 1200Mbps on the 2.4GHz and 5GHz bands. (1) Full Gigabit Ports: Enjoy fast, reliable wired connections for gaming and streaming at the best quality. Extensive Coverage: Beam forming and four antennas combine to deliver focused reception to devices far away. Easy Mesh Compatible: Provides whole home Wi-Fi coverage with standard mesh technology. (3) Enhanced Protection: Protect your network with firewalls, parental controls, and the latest WPA3 encryption. (2) Easy Setup: Set up your router in minutes with the intuitive web interface or Aginet app. Remote Management: Aginet ACS, TR-069, TR-181, TR-111, and TR-143 are supporte |
DEVICE INTERFACE | • 4 x 10/100/1000 Gigabit LAN Ports • 1 x 10/100/1000 Gigabit WAN Port • 1 x FXS VoIP / VoLTE / CS Ports • 802.11ac/n/g/b Wireless LAN 1 • CAT 4 LTE (Qualcomm solution) • Power Button • 1 x USB 3.0 Port |
ANTENNA CONFIGURATION | 2 x 5dBi detachable external LTE antennas • 2 x 5dBi Fixed external Wi-Fi Antennas |
SIGNAL DATA RATE | 2.4 GHz -300 Mbps 5 GHz- 866 Mbps LTE-DL150 Mbps UL 50 Mbps |
LTE SUPPORTED BAND | WCDMA: B1/5/8 FDD LTE: B1/B3/B5/B7/B8/B20 GSM: 850/900/1800/1900 TDD LTE: B38/B40 GSM: 850/900/1800/190 |
SECURITY | WPA & WPA2 (Wi-Fi Protected Access) Wi-Fi Protected setup (WPS) – PIN/PBC |
POWER | • Input: 100 ~240 V • Output: 12 V / 1.5 A |
POWER CONSUMPTION | 18W |
STORAGE TEMPERATURE | -20 to 70 °C (-4 to 158 °F) |
OPERATING TEMPERATURE | 0 to 45 °C (32 to 113 °F) |
HUMIDITY | 10 % ~ 95% non-condensing |
CONDITION | New |
DIMENSIONS | 210 x 150 x 37 mm (8.26 x 5.91 x 1.46 inches) |
WARRANTY | 12 Months warranty |
WHAT’S IN THE BOX | 1 x TP-Link EC220-G5 AC1200 Wireless Dual Band Gigabit Router 1 x Power Supply Unit 1 x RJ45 Ethernet Cable 1 x Quick Installation Guide |
